Steel Flashings & Fabrications



Why choose steel flashings and fabrications

Manufactured in-house our standard steel flashings are commonly kept in stock to accompany our stock sheeting.

Other bespoke flashings and gutters are available to order in different dimensions, colours, and finishes. All come in 3m lengths as standard.





Cut to length

Delivered with 4 days

Easy to install

One of the UK's largest stockist

Trimline gutters

Key features


A strong, versatile, and high-capacity gutter designed to suit buildings with profiled steel roofing and cladding. Manufactured to match the colour and finish of the cladding and or steel flashing of the building.


As standard we supply in 3m lengths, we can also supply 4m lengths in other colours and finishes that you may require.

Manufactured in 0.7mm thick in the following finishes:

  • Plain galvanised steel finish
  • Aluminium (0.9mm thick plain finish)
  • Plastisol Leather grain or Colour-coat HPS200
  • Silver PVdF or Prisma finishes
  • Polyester coated

Both galvanised and aluminium gutters can be powder coated to specified RAL numbers if required.

Joined together using 150mm long, internal butt straps and secured in place with sealant and either rivets or stitcher screws, with the majority of gutters fixed using support arms.

To manufacture your trimline gutters with support arms, we will require the angle of the roof pitch, along with the profile depth of the attached roof sheets.

If require any help to identify your sheet profile, please see below.

We also supply loose stop ends, to ensure water tightness these should be fixed to the trimline gutter using either stitcher screws or rivets along with a good quality sealant. Outlets for trimline gutters can be supplied in either galvanised steel or aluminium top hat sections in multiple diameters.

Square downpipes to suit the material and finish of the trimline gutter can be manufactured in 3m lengths.

In addition to large stocks off the shelf, Southern Sheeting can manufacture a range of bespoke flashings and gutters to your specifications.

Box gutters

Key features

Heavy duty box gutters can be manufactured to your specifications in either aluminium or galvanised steel. This type of gutter is mainly used on industrial and agricultural buildings.


Depending on the required application can be manufactured in multiple shapes and sizes and can be produced in either 1.5mm or 2.00mm thickness.

Box or valley gutters are predominantly manufactured in 3m lengths; however, we can also supply 4m lengths.

We recommend joining together by either:

  • Internal butt strap system – Using a combination or nuts, bolts, and mastic and will require drilling as required. Please note fixings will require ordering separately.

  • Joggle jointed system – the female end pressed into one of the end and holes punched in both ends for the nuts and bolts. Please note that all fixings and mastic are supplied with the joggle jointed gutter.


We can weld stop ends in place or these can be attached on site using nut, bolts, and mastic and weir outlets fabricated to your specifications.

Gutter outlets can be supplied in either 63mm, 75mm or 150mm diameter and manufactured in galvanised or aluminium.

Square downpipes to suit the material and finish of the trimline gutter can be manufactured in 3m lengths.

Colour and finish selector

Choose from our  wide range of colours and finishes

Stockists and distributors of  multi-type roofing and cladding sheets, cladding boards and associated sheet roofing products




Bespoke flashings and fabrications

Southern Sheeting can also manufacture a range of bespoke flashings and gutters to your specification.



If you need a price on any of these flashings or galvanised box type gutters, no matter what the shape please fill in our enquiry order form below or call our sales team.
